B760A-Silver (B760.S1700.ATX.DDR5)

Name: B760A-Silver (B760.S1700.ATX.DDR5)
SKU: 165967
Price: 120.32 EUR
Availability: InStock

€147.99

Biostar B760A-SILVER, Intel, LGA 1700, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, LGA 1700, DDR5-SDRAM, 192 GB

16 in stock

Categories: Mainboards & accessories, Motherboards - Intel

Description
Additional information

Description

Biostar B760A-SILVER. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processors: Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9. Supported memory: DDR5-SDRAM, Maximum RAM: 192 GB, Memory type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drives: HDD & SSD. Ethernet interface type: 2.5 Gigabit Ethernet, LAN controller: Realtek RTL8125B. Component for: PC, Motherboard form factor: micro ATX, Motherboard chipset family: Intel

Additional information

Processor manufacturer	Intel
Processor socket	LGA 1700
Compatible processors	Intel® Core ™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9
Maximum number of SMP processors	1
Supported processor slots	LGA 1700
Supported RAM	DDR5 SDRAM
Number of memory slots	4
RAM type	DIMM
Memory channels	Dual channel
Supported memory speed	5000,5200,5400,5600,5800,6000MHz
RAM memory maximum	192 GB
Supported storage drives	HDD & SSD
Supported storage drive interfaces	M.2, SATA III
Number of USB 2.0 interfaces	4
USB 3.2 Gen 1 (3.1 Gen 1) ports	1
USB 3.2 Gen 2 (3.1 Gen 2) ports	5
SATA III connectors	4
Characteristic	ATX power connector (24-pin), CPU fan connector, EPS power connector (8-pin), Ethernet/LAN, Front panel audio connector, Front panel connector, RGB LED header, TPM connector
Number of USB 2.0 ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports	3
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports	5
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type-C ports	2
Number of Ethernet LAN connections (RJ-45)	1
Number of PS / 2 connections	1
Number of VGA (D-Sub) connections	1
Number of HDMI connections	1
HDMI version	2.1
Number of DVI-D connections	1
Number of DisplayPort connections	1
DisplayPorts version	1.2
Ethernet interface type	2.5 Gigabit Ethernet
LAN controller	Realtek RTL8125B
Motherboard chipset	Intel B760
Audio chip	Realtek ALC1220
Audio channels	7.1 channels
PC health monitoring	Fan, Temperature, Voltage
Component for	Pc
Motherboard form factor	Micro ATX
Motherboard chipset family	Intel
Supports Windows operating systems	Windows 10 x64, Windows 11 x64
PCI-Express x1 (Gen 3.x) connectors	1
PCI-Express x16 (Gen 3.x) connectors	1
PCI Express x16 slots (Gen 4.x)	1
Number of M.2 (M) slots	1
Broad	305 mm
Depth	244 mm
Supplied cables	SATA
Manufacturer	BIOSTAR
