Biostar B650MT (B650.AM5.mATX.DDR5)

Name: Biostar B650MT (B650.AM5.mATX.DDR5)
SKU: 165396
Price: 98.67 EUR
Availability: InStock

€121.36

Biostar B650MT, AMD, Socket AM5, AMD Ryzen™ 7, Socket AM5, DDR5-SDRAM, 96 GB

50 in stock

Categories: Mainboards & accessories, Motherboards - AMD

Description
Additional information

Description

Biostar B650MT. Processor manufacturer: AMD, Processor socket: Socket AM5, Compatible processors: AMD Ryzen™ 7. Supported memory: DDR5-SDRAM, Maximum RAM: 96 GB, Memory type: DIMM. Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III, Supported storage drives: HDD & SSD, RAID levels: 0, 1, 10. Maximum resolution: 4096 x 2160 pixels. Ethernet interface type: Gigabit Ethernet, LAN controller: Realtek RTL8111H

Additional information

Processor manufacturer	AMD
Processor socket	Socket AM5
Compatible processors	AMD Ryzen™ 7
Supported processor slots	Socket AM5
Supported RAM	DDR5 SDRAM
Number of memory slots	2
RAM type	DIMM
Memory channels	Dual channel
ECC compatibility	Non-ECC
Supported memory speed	4800, 5200, 5400, 5600, 6000 MHz
RAM memory maximum	96GB
Supported memory module capacities	16 GB, 32GB, 48GB, 8GB
Supported storage drives	HDD & SSD
Supported storage drive interfaces	M.2, PCI Express 4.0, SATA III
Characteristic	12V power connection, ATX power connector (24-pin), Audio connection, Clear CMOS jumper, CPU fan connector, Drivers included, Ethernet/LAN, Front panel audio connector, Front panel connector, HDCP, RAID support, TPM connector
RAID level	1, 10
Maximum resolution	4096 x 2160 pixels
DirectX version	12.0
Number of USB 2.0 interfaces	2
USB 3.2 Gen 1 (3.1 Gen 1) ports	1
USB 3.2 Gen 2 (3.1 Gen 2) ports	1
SATA III connectors	4
Number of chassis fan plugs	1
Number of COM plugs	1
Number of USB 2.0 ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports	4
Number of Ethernet LAN connections (RJ-45)	1
Number of HDMI connections	1
HDMI version	1.4
Number of DisplayPort connections	1
DisplayPorts version	1.2
Ethernet interface type	Gigabit Ethernet
LAN controller	Realtek RTL8111H
Motherboard chipset	AMD B650
Audio chip	Realtek ALC897
Audio channels	7.1 channels
Product color	Black, Silver
PC health monitoring	CPU, Fan, Temperature, Voltage
Component for	Pc
Motherboard form factor	Micro ATX
Motherboard chipset family	AMD
Supports Windows operating systems	Windows 10 x64, Windows 11 x64
PCI-Express x1 (Gen 3.x) connectors	1
PCI Express x16 slots (Gen 4.x)	1
Number of M.2 (M) slots	1
Broad	221 mm
Depth	235 mm
Supplied cables	SATA
Supplied software	BullGuard
Manufacturer	BIOSTAR
