Cisco CATALYST 9200L 48-PORT POE+

Name: Cisco CATALYST 9200L 48-PORT POE+
SKU: 236450
Price: 4155.40 EUR
Availability: InStock

€5,111.14

Cisco Catalyst 9200L, Managed, L3, Gigabit Ethernet (10/100/1000), Full Duplex, Power over Ethernet (PoE)

50 in stock

Categories: network, Switching Hubs

Description
Additional information

Description

Cisco Catalyst 9200L. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Number of basic switching RJ-45 Ethernet ports: 48. Full duplex. MAC address table: 16,000 entries. Routing/switching capacity: 104 Gbps. Network standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE…. Power connector: AC input jack. Power over Ethernet (PoE)

Additional information

Switch type	Managed
Switch level	L3
Characteristic	10G support, Access control list, ARP inspection, Configuring Site Settings (CLI), Full duplex, IP routing, Jumbo frames support, Multicast support, Power over Ethernet (PoE), Power supply included, Quality of Service (QoS) Support, Spanning tree protocol, Support data flow control, Support for redundant power supply, Traffic classification, VLAN support, Web-based management
Number of basic switching RJ-45 Ethernet ports	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Number of Gigabit Ethernet (copper) connections	4
Power plug	AC input socket
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T, 10GBase-T
Routing inputs	3000
Number of VLANs	4096
Routing / switching capacity	104 Gbit / s
Transfer rate	77.38 MPps
MAC address table	16,000 entries
Jumbo frames	9198
Data packet buffer memory	6 MB
Supported security algorithms	128-bit AES
Multicast MAC address table	1000 entries
IPv4 multicast entries	3000
IPv6 multicast entries	1500
Management logs	SNMPv1 / v2c / v3
Router protocol	CDP, EIGRP, OSPF, RIP, VRRP
Product color	Gray
Storage type	DRAM
Storage capacity	2000 MB
Flash memory	4000 MB
AC input voltage	100-240V
AC input frequency	50-60 Hz
Input current	1.6 – 0.7 A
Power consumption (standard operation)	125 W
Number of Power over Ethernet plus (PoE +) connections	48
Operating temperatur	5 – 45 ° C
Storage temperature range	40 – 70 ° C
Relative humidity in operation	5 – 90%
Height during operation	0 – 3000 m
Broad	445 mm
Depth	288 mm
Height	44 mm
Packaging type	Box
Certification	AS/NZS 60950.1, CAN/CSA C22.2 No. 60950-1, EN 60950-1, IEC 60950-1, RoHS, UL 60950-1
Goods tariff number (HS)	85176990
Manufacturer	Cisco
