Converter GVT-2015 10/100/1000T>RJ45 to SFP 60W sw
€127.86
LevelOne RJ45 to SFP Gigabit Media Converter, 802.3bt 60W PoE PSE, 1000 Mbps, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE…, Fast Ethernet, Gigabit Ethernet, 10, 100, 1000 Mbps, 100BASE-TX, 1000BASE-T, 1000BASE-X, Multi-Mode, Single-Mode
- Description
- Additional information
Description
LevelOne RJ45 to SFP Gigabit Media Converter, 802.3bt 60W PoE PSE. Maximum data transfer rate: 1000 Mbps. Network standard: IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE…. Ethernet interface type: Fast Ethernet, Gigabit Ethernet. Cable mode structure: Multi-mode, Single-mode. LED indicators: LAN, PoE, Power. Product color: Black. Optical cable connector: SFP. Transmission technology: Wired. Input voltage: 100-240 V, AC input frequency: 50-60 Hz, Input current: 1.8 A.
The LevelOne GVT-2015 is a single-port, end-span IEEE 802.3bt High Power over Ethernet media converter with a total PoE budget of 60 watts. It is specifically designed to meet the growing power demands of network devices such as PTZ (pan, tilt, and zoom) network cameras, PTZ speed domes, color touchscreen VoIP phones, multi-channel (IEEE 802.11a/b/g/n/ac/ax) wireless LAN access points, and other network devices that require higher power to function properly. Equipped with an SFP port for Gigabit SFP transceivers, it is compatible with both multi-mode and single-mode fibers, depending on the transceiver choice. Thanks to its high Power over Ethernet performance, the GVT-2015 is the ideal solution for delivering data and power directly to network devices via the RJ45 interface without the need to install additional sockets and electrical cables.
Additional information
| Maximum data transfer rate | |
|---|---|
| Network standard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Ethernet interface type | |
| Ethernet LAN data transfer rates | |
| Copper ethernet cabling technology | |
| Characteristic | AC power adapter, Auto MDI/MDI-X, Auto-negotiation function, Direct current connection (DC), Jumbo frames support, Power over Ethernet (PoE), Quick installation guide, Support data flow control |
| Jumbo frames | |
| Cable fashion structure | Multi mode, Single mode |
| LED indicators | LAN, Perfomance, PoE |
| Product color | |
| Transmission technology | |
| Number of Ethernet LAN connections (RJ-45) | |
| Number of fiber connections | |
| Optical cable connector | |
| Number of Power over Ethernet plus (PoE +) connections | |
| Input voltage | |
| AC input frequency | |
| Input current | |
| Output voltage | |
| Output current | |
| Power consumption (standard operation) | |
| Power consumption (max.) | |
| Total power over Ethernet (PoE) | |
| Broad | |
| Depth | |
| Height | |
| Weight | |
| Operating temperatur | 0 – 50 ° C |
| Storage temperature range | |
| Relative humidity in operation | |
| Storage humidity | |
| Packaging width | |
| Packaging depth | |
| Packing height | |
| Package weight | |
| Certificates of conformity | CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD), RCM, RoHS, UKCA |
| Country of origin | |
| Number of boxes per pallet (air) | |
| Pallet length (gross) | 100 cm |
| Pallet width (gross) | 120 cm |
| Pallet height (air) | |
| Goods tariff number (HS) | 851762 |
| Width of the shipping box | |
| Shipping box length | |
| Shipping box height | |
| Shipping box weight | |
| Number of products per shipping carton | 10 piece (s) |
| Manufacturer |
