DIGITUS HDMI KVM IP Extender Receiver, Full HD 1.2m cable
€131.57
Digitus HDMI KVM IP Extender Receiver, Full HD, Receiver, Wired, 120 m, Cat5e, 1920 x 1080 pixels, 1920×1080 60Hz
- Description
- Additional information
Description
Digitus HDMI KVM IP Extender Receiver, Full HD. Type: Receiver, Transmission technology: Wired, Maximum possible transmission distance: 120 m. Receiver local video connection type: HDMI, Receiver local keyboard/mouse connection type: USB. USB port type: USB Type-A, USB data transfer rates: 480 Mbps. Input current: 1 A, Power consumption (receiver) (max.): 3.5 W, DC voltage: 5 V. Receiver width: 9 cm, Receiver depth: 11 cm, Receiver height: 2.7 cm.
Expand the HDMI KVM IP Extender Set (DS-55529) with additional receiver units to display your AV content on multiple screens (up to 253) simultaneously
– DS-55529 can be expanded to up to 253 screens (receivers)
– KVM function for connecting mouse/keyboard to control the signal source on the output screen
– Supports resolutions up to 1080p/60Hz, Full HD
– Supports CAT 5e (or higher) network cables
– Easy installation thanks to Plug & Play – no additional software/drivers or similar required
– HDMI 1.3
– HDCP 1.4
Expand the HDMI KVM IP Extender Set (DS-55529) with additional receiver units to simultaneously display your AV content on multiple monitors. The set extends Full HD AV signals over a CAT5e (or higher) network cable (point-to-point connection) up to 120 m. Furthermore, using network switches and the individual receiver units (DS-55530), you can distribute your video content to up to 253 displays over the existing network (IP connection) and extend it over an unlimited distance. Thanks to KVM functionality, a mouse/keyboard can be connected to the receiver, allowing control of the signal source on the output screen.
Additional information
| Transmission technology | |
|---|---|
| Maximum possible transmission distance | |
| Supported cable types | |
| Resolution (maximum, digital) | |
| Supported resolution | |
| Product color | |
| Material | |
| Characteristic | AC power adapter, Direct current connection (DC), Easy installation, LED indicators, Operating manual, Plug & Play |
| Receiver local video connection type | HDMI |
| Receiver local keyboard/mouse connection type | USB |
| Number of RJ-45 ports (receiver) | |
| USB port type | |
| Number of USB 2.0 ports | |
| HDMI version | |
| USB data transfer rates | |
| Number of RJ-45 ports | |
| Input current | |
| Power consumption (receiver) (max.) | 3.5 W |
| DC voltage | 5 V |
| Width of the receiver | 9 cm |
| Depth of the receiver | |
| Height of the receiver | 2.7 cm |
| Receiver weight | 244g |
| Packaging width | |
| Packaging depth | |
| Packing height | |
| Package weight | |
| Operating temperatur | 10 – 60 ° C |
| Packaging volume | |
| Country of origin | |
| VK customs tariff code | 85176200 |
| Manufacturer |
