DIGITUS HDMI Matrix Switch 4K/30Hz, 4×2

Description

Digitus 4×2 HDMI Matrix Switch / Multi-Viewer, 4K/30Hz. Product type: AV matrix switcher, bandwidth: 10.2 Gbps. Housing color: Black, housing material: Metal, controls: buttons, remote. USB connector: Micro-USB A, headphone jack: 3.5 mm. Power consumption (standard operation): 5 W, output current: 1000 mA, output voltage: 5 V. Width: 91 mm, depth: 214 mm, height: 18.5 mm.

Easily switch between up to 4 HDMI sources and 2 playback devices and distribute your media content independently of each other / Multi-Viewer offers 6 modes for individual display of the sources (split screen, PIP)

– Switch between up to 4 HDMI sources and 2 playback devices via remote control, on the device itself or via RS232 control
– Multi-Viewer: 6 modes for individual display of the sources on HDMI output A (primary) or on HDMI output A & B simultaneously (secondary) via remote control or on the device itself
– Audio Extractor: Toslink / Stereo (3.5 mm) – Extraction / separate playback of the audio signal
– Max. resolution: 4K/30Hz
– RS232 control via Micro USB port
– Scaler (switcher) – Adjustment of the HDMI output resolution (1080p, 1600p, 4K/30Hz)
– Separate on/off switch
– Video bandwidth: 10.2 Gbps
– HDCP 1.4
– HDMI 1.4

The DIGITUS® 4×2 HDMI Matrix Switch / Quad Multi-Viewer allows convenient switching between up to 4 HDMI sources and 2 playback devices, distributing your media content independently. Easily switch between signal sources via remote control, on the device itself, or via RS232 control. The multi-viewer function offers 6 modes for individual source display (split screen, PIP) on output A or A & B in parallel. Audio signals can also be extracted via Toslink or 3.5 mm stereo connection and played back separately. Resolutions up to 4K/30Hz are supported. The HDMI output resolution can be individually adjusted using a scaler.
