GA-Z790 D (1700) (D)

Name: GA-Z790 D (1700) (D)
SKU: 169341
Price: 149.63 EUR
Availability: InStock

€184.04

GIGABYTE Z790 D, Intel, LGA 1700, Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,…, LGA 1700, 192 GB, DDR5-SDRAM

20 in stock

Categories: Mainboards & accessories, Motherboards - Intel

Description
Additional information

Description

GIGABYTE Z790 D. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processors: Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9,…. Supported memory: DDR5-SDRAM, Maximum RAM: 192 GB, Memory type: DIMM. Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III, Supported storage drives: HDD & SSD, RAID levels: 0, 1, 5, 10. Maximum resolution: 4096 x 2304 pixels. USB connectors: USB Type-A, USB Type-C

Additional information

Processor manufacturer	Intel
Processor socket	LGA 1700
Compatible processors	Intel® Celeron®, Intel® Core ™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
Maximum number of SMP processors	1
Supported processor slots	LGA 1700
Maximum internal memory supported by the processor	192 GB
Supported RAM	DDR5 SDRAM
Number of memory slots	4
RAM type	DIMM
Memory channels	Dual channel
ECC compatibility	ECC & Non-ECC
Supported memory speed	4400,4800,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600MHz
Supported memory clock speed (max.)	7600MHz
RAM memory maximum	192 GB
Supported memory module capacities	12GB, 16 GB, 1GB, 2GB, 32GB, 48GB, 4GB, 8GB
Characteristic	12V power connection, Antenna included, ATX power connector (24-pin), Batteries included, Clear CMOS button, Clear CMOS jumper, CPU fan connector, Discrete graphics support, EPS power connector (8-pin), Ethernet/LAN, Front panel audio connector, Front panel connector, HDCP, Microphone input, RAID support, RGB LED header, S/PDIF output, TPM connector, Unbuffered memory
Supported storage drives	HDD & SSD
Supported storage drive interfaces	M.2, PCI Express 4.0, SATA III
Maximum number of HDDs supported	4
Number of storage drives supported	7
RAID level	1, 10, 5
Parallel processing technology	Unsupported
Maximum resolution	4096 x 2304 pixels
DirectX version	12.0
Number of USB 2.0 interfaces	2
USB 3.2 Gen 1 (3.1 Gen 1) ports	1
USB 3.2 Gen 2 (3.1 Gen 2) ports	1
SATA III connectors	4
Total number of SATA ports	4
Number of EATX power plugs	2
Thunderbolt headers	2
Number of USB 2.0 ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports	4
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports	1
USB 3.2 Gen 2x2 Type-C number of ports	1
Number of Ethernet LAN connections (RJ-45)	1
Number of HDMI connections	1
HDMI version	2.1
Number of DisplayPort connections	1
DisplayPorts version	1.2
Headphone outputs	1
WiFi AP antenna socket	2
USB plug	USB Type-A, USB Type-C
Ethernet interface type	2.5 Gigabit Ethernet
Motherboard chipset	Intel Z790 Express
Audio chip	Realtek ALC897
Audio channels	7.1 channels
Product color	Brown
PC health monitoring	Fan, Temperature, Voltage, Water cooling
Component for	Pc
Motherboard form factor	ATX
Motherboard chipset family	Intel
Energy source	ATX
Supports Windows operating systems	Windows 10 x64, Windows 11 x64
PCI-Express x1 (Gen 3.x) connectors	2
PCI-Express x16 (Gen 3.x) connectors	1
PCI Express x16 slots (Gen 4.x)	1
PCI Express x16 slots (Gen 5.x)	1
Number of M.2 (M) slots	3
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
ACPI version	5.0
Desktop Management Interface (DMI) version	2.7
System management BIOS (SMBIOS) version	2.7
Country of origin	China
Quantity per shipping box	1 piece (s)
Battery weight	3 g
Lithium weight per battery	0.07g
Number of battery cells	1
Rechargeable battery technology	Lithium Manganese Dioxide (LiMnO2)
Accumulator / battery type	CR2032
Packaging width	335 mm
Packaging depth	270 mm
Packing height	80 mm
Package weight	1.8 kg
Broad	305 mm
Depth	244 mm
Height	35 mm
Supplied cables	SATA
Supplied software	Norton® Internet Security (OEM version)LAN bandwidth management software
Warranty period	3 year (s)
Manufacturer	Gigabyte
