HUAWEI Data Communication S310S-8P4JX S310S-8P4JX S310S-8P4JX 8×10/100/1000BASE-T ports 128W PoE+ 2x10GE SFP+ ports 2×2.5GE

Name: HUAWEI Data Communication S310S-8P4JX S310S-8P4JX S310S-8P4JX 8x10/100/1000BASE-T ports 128W PoE+ 2x10GE SFP+ ports 2x2.5GE
SKU: 214820
Price: 165.08 EUR
Availability: InStock

€203.05

HUAWEI eKit S310S Series S310S-8P4JX, Managed, L2+, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), rack installation, 1U

2 in stock

Categories: network, Switching Hubs

Description
Additional information

Description

HUAWEI eKit S310S Series S310S-8P4JX. Switch type: Managed, Switch level: L2+. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Number of basic switching RJ-45 Ethernet ports: 8. MAC address table: 16000 entries. Routing/switching capacity: 66 Gbps. Network standard: IEEE 802.1D, IEEE 802.1s, IEEE 802.1w. Power connector: AC input jack. Power over Ethernet (PoE). Rack-mountable, form factor: 1U.

Additional information

Switch type	Managed
Switch level	L2 +
Characteristic	10G support, Access control list, Broadcast storm control, Cloud managed, IGMP proxy, IGMP snooping, LED indicators, Multicast support, Policy-based routing, Port mirroring, Power over Ethernet (PoE), Power supply included, Quality of Service (QoS) Support, Quick start overview, Rack installation, Rate Limiting, VLAN support, Web-based management
Number of basic switching RJ-45 Ethernet ports	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Number of Gigabit Ethernet (copper) connections	8
Quantity of SFP module slots	2
Quantity of SFP + module slots	2
Power plug	AC input socket
Network standard	IEEE 802.1D, IEEE 802.1s, IEEE 802.1w
Number of VLANs	4096
Routing / switching capacity	66 Gbps
Transfer rate	49 Mpps
MAC address table	16,000 entries
DHCP functions	DHCP client, DHCP snooping
Supported security algorithms	HTTPS, SSH
Form factor	1U
Product color	Gray
Energy source	AC
Number of power supply units	1
AC input voltage	100-240V
AC input frequency	50/60 Hz
Number of Power over Ethernet plus (PoE +) connections	8
Total power over Ethernet (PoE)	128W
Operating temperatur	5 – 40 ° C
Storage temperature range	40 – 70 ° C
Relative humidity in operation	5 – 95%
Broad	320 mm
Depth	210 mm
Height	43.6 mm
Manufacturer	HUAWEI
