HUAWEI S220-8T4S 8×10/100/1000BASE-T ports 4xGE SFP ports AC power eKit

Name: HUAWEI S220-8T4S 8x10/100/1000BASE-T ports 4xGE SFP ports AC power eKit
SKU: 214767
Price: 120.70 EUR
Availability: InStock

€148.46

HUAWEI eKit S220 Series S220-8T4S, Managed, L2, Gigabit Ethernet (10/100/1000), Rack Mount, 1U

2 in stock

Categories: network, Switching Hubs

Description
Additional information

Description

HUAWEI eKit S220 Series S220-8T4S. Switch type: Managed, Switch level: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Number of basic switching RJ-45 Ethernet ports: 8. Console port: RJ-45. MAC address table: 16000 entries. Routing/switching capacity: 24 Gbps. Rack mountable, form factor: 1U.

Additional information

Switch type	Managed
Switch level	L2
Characteristic	Access control list, Cloud managed, Configuring Site Settings (CLI), LED indicators, Link aggregation, Loop protection, Multicast support, Power supply included, Quality of Service (QoS) Support, Rack installation, Rate Limiting, Static route, VLAN support
Number of basic switching RJ-45 Ethernet ports	8
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Quantity of SFP module slots	4
Console port	RJ-45
Number of VLANs	4094
Routing / switching capacity	24Gbps
Transfer rate	18 MPps
MAC address table	16,000 entries
DHCP functions	DHCP client, DHCP server, DHCP snooping
Supported security algorithms	SNMP, SNMPv2, SNMPv3
Authentication	MAC based authentication
Authentication type	IEEE 802.1x
Form factor	1U
Product color	Gray
Housing material	Metal
International protection class (IP code)	IP20
Number of fans	1 fan
Noise level	44.5 dB
Energy source	AC
AC input voltage	100-240V
AC input frequency	50/60 Hz
Power consumption (max.)	21.52 W
Operating temperatur	5 – 50 ° C
Storage temperature range	40 – 70 ° C
Relative humidity in operation	5 – 95%
Height during operation	0 – 5000 m
Storage height	0 – 5000 m
Broad	250 mm
Depth	187 mm
Height	43.6 mm
Package weight	2.22 kg
Manufacturer	HUAWEI
