HUAWEI S620-24T16X8Y2CZ 24×10/100/1000BASE-T ports 16x10GE SFP+ ports 8x25GE SFP28 ports 2x100GE QSFP28 ports exp card slot eKit

Name: HUAWEI S620-24T16X8Y2CZ 24x10/100/1000BASE-T ports 16x10GE SFP+ ports 8x25GE SFP28 ports 2x100GE QSFP28 ports exp card slot eKit
SKU: 214797
Price: 924.86 EUR
Availability: InStock

€1,137.58

HUAWEI eKit S600 Series S620-24T16X8Y2CZ, Managed, L3, Gigabit Ethernet (10/100/1000), Rack Mount, 1U

1 in stock

Categories: network, Switching Hubs

Description
Additional information

Description

HUAWEI eKit S600 Series S620-24T16X8Y2CZ. Switch type: Managed, Switch level: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Number of basic switching RJ-45 Ethernet ports: 24. MAC address table: 64000 entries, Routing/switching capacity: 1168 Gbps. Network standards: IEEE 802.1D, IEEE 802.1ag, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x. DC input voltage: 48-60 V. Rack mount, form factor: 1U.

Additional information

Switch type	Managed
Switch level	L3
Characteristic	10G support, Access control list, ARP inspection, Broadcast storm control, Cloud managed, Head-of-Line (HOL) blocking, IGMP snooping, LED indicators, Link aggregation, Loop protection, Multicast support, Operating manual, Power supply included, Quality of Service (QoS) Support, Rack installation, Rate Limiting, Spanning tree protocol, SSH/SSL support, Traffic shaping, VLAN support, Web-based management
Number of basic switching RJ-45 Ethernet ports	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Quantity of SFP module slots	8
Quantity of SFP + module slots	16
Number of QSFP28 ports	2
Network standard	IEEE 802.1ag, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x
Number of VLANs	4000
Routing / switching capacity	1168 Gbit/s
Transfer rate	867 MPps
MAC address table	64,000 entries
Supported security algorithms	SNMP, SNMPv2, SNMPv3
Authentication	MAC based authentication, Port based authentication
Authentication type	HWTACACS, Network Access Control (NAC), RADIUS
Management logs	SNMPv1/v2/v3
Supported network protocols	BGP, BGP4+, IS-IS, IS-ISv6, OSPF, OSPFv3, RIP, RIPng
Form factor	1U
Product color	Gray
Energy source	AC
AC input voltage	100-240V
AC input frequency	50/60 Hz
DC input voltage	48 – 60 V
Power consumption (standard operation)	122 W
Power consumption (max.)	127 W.
Operating temperatur	5 – 45 ° C
Storage temperature range	40 – 70 ° C
Relative humidity in operation	5 – 95%
Storage humidity	5 – 95%
Broad	442 mm
Depth	420 mm
Height	43.6 mm
Weight	6.31kg
Manufacturer	HUAWEI
