Intel S4677 XEON GOLD 6534 TRAY

Name: Intel S4677 XEON GOLD 6534 TRAY
SKU: 253773
Price: 2377.93 EUR
Availability: InStock

€2,924.85

Intel Xeon Gold 6534, Intel® Xeon® Gold, LGA 4677 (Socket E), Intel, 3.9 GHz, 64-bit, Intel Xeon Scalable 5th Gen

2 in stock

Categories: CPUs, Intel CPUs

Description
Additional information

Description

Intel Xeon Gold 6534. Processor family: Intel® Xeon® Gold, Processor socket: LGA 4677 (Socket E), Processor manufacturer: Intel. Memory channels: Octa-Channel, Maximum internal memory supported by processor: 4 TB, Memory types supported by processor: DDR5 SDRAM. Market segment: Server, Usage conditions: Server/Enterprise, Supported instruction sets: AMX, AVX, AVX 2.0, AVX-512, SSE4.2. Maximum enclave size supported for Intel® SGX: 128 GB, Intel® Data Streaming Accelerator (DSA): 1 default device. Maximum RAM: 4 TB

Additional information

Processor manufacturer	Intel
Processor generation	Intel Xeon 5th Gen
Processor	6534
Base frequency of the processor	3.9 GHz
Processor family	Intel® Xeon® Gold
Number of CPU cores	8
Processor socket	LGA 4677 (Socket E)
Processor threads	16
Intel® UPI Speed	20 GT/s
Processor operating modes	64-bit
Processor boost frequency	4.2 GHz
Processor cache	22.5MB
Thermal Design Power (TDP)	195 W
Stepping	R1
Processor code name	Emerald Rapids
ARK processor detection	237555
Maximum internal memory supported by the processor	4 TB
Memory types supported by the processor	DDR5 SDRAM
Memory clock rates supported by the processor	4800 MHz
Memory channels	Octa channel
Characteristic	ECC, Enabling Intel® On Demand features, Execute disable bit, Intel® 64, Intel® Advanced Matrix Extensions (AMX), Intel® AES New Instructions (Intel® AES-NI), Intel® Boot Guard, Intel® Control-flow Enforcement Technology (CET), Intel® Crypto Acceleration, Intel® Deep Learning Boost (Intel® DL Boost) on CPU, Intel® Hyper-Threading Technology (Intel® HT Technology), Intel® OS Guard, Intel® QuickAssist Software Acceleration, Intel® Resource Director Technology (Intel® RDT), Intel® Run Sure Technology, Intel® Software Guard Extensions (Intel® SGX), Intel® Speed Select Technology – Core Performance, Intel® Speed Select Technology – Turbo Frequency, Intel® Speed Shift Technology, Intel® Total Memory Encryption, Intel® Total Memory Encryption – Multi Key, Intel® Transactional Synchronization Extensions, Intel® Trusted Execution Technology, Intel® Virtualization Technology (VT-X), Intel® Virtualization Technology for Direct I/O (VT-d), Intel® Volume Management Device (VMD), Intel® VT-x with Extended Page Tables (EPT), Mode-based Execute Control (MBE), Support for Intel® Platform Firmware Resilience
Built-in graphics card model	Not available
Separate graphics card model	Not available
Market segment	Server
Terms of Use	Server/Enterprise
Maximum number of PCI Express lanes	80
PCI Express slots version	5.0
Supported instruction sets	AMX, AVX, AVX 2.0, AVX-512, SSE4.2
Scalability	2S
Export Control Classification Number (ECCN)	5A992C
Automated Tracking Goods Classification System (CCATS)	740.17B1
Intel® Turbo Boost Technology	2.0
Maximum enclave size support for Intel® SGX	128 GB
AVX-512 Secured Multiply-Add (FMA) units	2
Intel® Data Streaming Accelerator (DSA)	1 default devices
Tcase	64°C
DTS Max	97 ° C
Start date	Q4'23
Status	Launched
Number of UPI links	3
Parcel carrier	E1B
Maintenance status	Baseline Servicing
Goods tariff number (HS)	8542310001
RAM memory maximum	4 TB
Manufacturer	Intel
