NETGEAR Switch 14x GE MSM4214X-100EUS (14-AV) AV Line

Name: NETGEAR Switch 14x GE MSM4214X-100EUS (14-AV) AV Line
SKU: 224844
Price: 1149.21 EUR
Availability: InStock

€1,413.53

NETGEAR M4250-12M2XF, Managed, L2/L3, 2.5G Ethernet, Full Duplex, Rack Mount, 1U

1 in stock

Categories: network, Switching Hubs

Description
Additional information

Description

NETGEAR M4250-12M2XF. Switch type: Managed, Switch layer: L2/L3. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet, Number of basic switching RJ-45 Ethernet ports: 12, full duplex. MAC address table: 16,000 entries, Routing/switching capacity: 100 Gbps. Network standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE…. Rack-mountable, form factor: 1U

Additional information

Switch type	Managed
Switch level	L2 / L3
Characteristic	Access control list, BPDU filtering/protection, Broadcast storm control, Built-in processor, Full duplex, IGMP snooping, Jumbo frames support, Link aggregation, Loop protection, Multicast support, Quality of Service (QoS) Support, Rack installation, Rate Limiting, Spanning tree protocol, SSH/SSL support, Store and forward, VLAN support
Number of basic switching RJ-45 Ethernet ports	12
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet
Quantity of SFP + module slots	2
Network standard	IEEE 802.1ab, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x
Virtual LAN functions	MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN
Number of VLANs	4093
Routing / switching capacity	100 Gbit / s
Passage	74.4 Mbps
MAC address table	16,000 entries
Waiting time (1 Gbps)	1.186 µs
Number of queues	8
Jumbo frames	12000
Data packet buffer memory	16 MB
DHCP functions	DHCP option 82, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 server, DHCPv6 snooping
Authentication	MAC based authentication
Authentication type	RADIUS
IPv4 multicast entries	2000
IPv6 multicast entries	2000
Form factor	1U
Product color	Black
LED indicators	Perfomance, PoE, Status
Processor	ARM Cortex-A9
Processor clock frequency	1250MHz
Storage capacity	2048 MB
Noise level	46.4 dB
Mean Time Between Failures (MTBF)	720892 hours
Power consumption (standard operation)	37.9 W
Operating temperatur	0 – 50 ° C
Storage temperature range	20 – 70 ° C
Relative humidity in operation	0 – 90%
Storage humidity	0 – 95%
Height during operation	0 – 3000 m
Storage height	0 – 3000 m
Heat dissipation	129.39 BTU/h
Broad	440 mm
Depth	100 mm
Height	43.2 mm
Weight	1.75 kg
Goods tariff number (HS)	85176990
Manufacturer	NETGEAR
