NETGEAR Switch 8x 2.5GE MS108UP-100EUS unmanaged

Name: NETGEAR Switch 8x 2.5GE MS108UP-100EUS unmanaged
SKU: 224886
Price: 245.10 EUR
Availability: InStock

€301.47

NETGEAR MS108UP, Unmanaged, 2.5G Ethernet (100/1000/2500), full duplex, Power over Ethernet (PoE), wall mount

2 in stock

Categories: network, Switching Hubs

Description
Additional information

Description

NETGEAR MS108UP. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports: 2.5G Ethernet (100/1000/2500). Number of basic switching RJ-45 Ethernet ports: 8. Full duplex. MAC address table: 16,000 entries. Routing/switching capacity: 40 Gbps. Network standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt. DC input voltage: 54 V. Power over Ethernet (PoE). Wall-mountable.

Additional information

Switch type	Unmanaged
Characteristic	Auto MDI/MDI-X, Auto-scan, Fanless, Full duplex, Half duplex, Head-of-Line (HOL) blocking, Jumbo frames support, Power over Ethernet (PoE), Power supply included, Quality of Service (QoS) Support, VLAN support, Wall mounting
Number of basic switching RJ-45 Ethernet ports	8
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Number of 2.5G Ethernet (copper) ports	8
Network standard	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data transfer rates	100,1000,2500 Mbit / s
Number of VLANs	64
Routing / switching capacity	40 Gbit / s
MAC address table	16,000 entries
Waiting time (1 Gbps)	3.593 µs
Jumbo frames	12000
Packet forwarding rate (1 Gbit / s)	1488000 pps
Data packet buffer memory	1.5 MB
Housing material	Metal
LED indicators	Activity, Link, Perfomance, PoE
Number of fans	0 fans
Electromagnetic compatibility	BSMI, CCC, CE, FCC Part 15 Class B, ISED, KC, RCM, VCCI
Mean Time Between Failures (MTBF)	373643.7 hours
Energy source	Direct current
DC input voltage	54 V
Input current	4.7 A
Number of Power over Ethernet plus (PoE +) connections	8
Total power over Ethernet (PoE)	230 W
Operating temperatur	0 – 40 ° C
Storage temperature range	20 – 70 ° C
Relative humidity in operation	0 – 90%
Height during operation	0 – 3000 m
Heat dissipation	923.49 BTU/h
Broad	210 mm
Depth	140 mm
Height	40 mm
Weight	900 g
Certification	BSMI, CB, CCC, CSA, RCM
Goods tariff number (HS)	85176990
Manufacturer	NETGEAR
