Switch 24x GE GES-2128P 4xGSFP 19″ 380W 24xPoE+
€486.34
LevelOne Hilbert 28-Port Gigabit PoE Smart Lite Switch, 24 PoE Outputs, 4 x Gigabit SFP/RJ45 Combo, 802.3at/af PoE, 380W PoE Power Budget, Managed, L2, Gigabit Ethernet (10/100/1000), Full Duplex, Power over Ethernet (PoE), Rack Mount
- Description
- Additional information
Description
LevelOne Hilbert 28-Port Gigabit PoE Smart Lite Switch, 24 PoE outputs, 4 x Gigabit SFP/RJ45 Combo, 802.3at/af PoE, 380W PoE power budget. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000). Number of basic switching RJ-45 Ethernet ports: 24. Full duplex. MAC address table: 8000 entries. Routing/switching capacity: 56 Gbps. Network standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE…. Power over Ethernet (PoE). Rack-mountable.
The LevelOne Hilbert GES-2128P Gigabit PoE Smart Lite Switch is a next-generation Ethernet switch that delivers powerful PoE functionality and ease of use, enabling cost-effective Ethernet services over copper connections. The GES-2128P offers 24 (10M/100M/1G) RJ45 PoE+ ports (supporting 802.3at/af, and a total of up to 380W) and 4 Gigabit Combo RJ45/SFP slots. With the new LevelOne IP Locator, the easy-to-use switch discovery software, all Hilbert series switches can be searched and information about the switch and its IP configuration can be displayed. It is compatible with most Windows and Mac operating systems.
The LevelOne GES-2128P offers high hardware performance and environmental flexibility for enterprises. The GES-2128P is ideal for easy management, optimal usability, and lower total cost of ownership.
Additional information
| Switch type | |
|---|---|
| Switch level | |
| Characteristic | Auto-aging of MAC addresses supported, Broadcast storm control, Full duplex, IGMP snooping, Jumbo frames support, Link aggregation, Multicast support, Port mirroring, Power over Ethernet (PoE), Pressure rise protection, Quality of Service (QoS) Support, Quick start overview, Rack installation, Rack mounting kit, Rate Limiting, Self-learning of MAC addresses supported, Support data flow control, VLAN support, Web-based management |
| Number of basic switching RJ-45 Ethernet ports | |
| Basic switching RJ-45 Ethernet ports type | |
| Number of Gigabit Ethernet (copper) connections | |
| Number of combo SPF ports | |
| Network standard | IEEE 802.1p, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Copper ethernet cabling technology | |
| Virtual LAN functions | |
| Number of VLANs | |
| Routing / switching capacity | |
| MAC address table | |
| Number of queues | |
| Jumbo frames | |
| Data packet buffer memory | |
| Product color | |
| LED indicators | Activity, Link, Perfomance, PoE, System |
| Flash memory | |
| Noise level | |
| Mean Time Between Failures (MTBF) | |
| Energy source | |
| AC input voltage | |
| AC input frequency | |
| Power consumption (max.) | |
| Pressure rise protection voltage | 8 kV |
| Number of Power over Ethernet plus (PoE +) connections | |
| Power over Ethernet (PoE) power per connection | |
| Total power over Ethernet (PoE) | |
| Operating temperatur | 0 – 45 ° C |
| Storage temperature range | |
| Relative humidity in operation | |
| Storage humidity | |
| Heat dissipation | |
| Broad | |
| Depth | |
| Height | |
| Weight | |
| Supplied cables | |
| Packaging type | |
| Packaging width | |
| Packaging depth | |
| Packing height | |
| Package weight | |
| Number of boxes per pallet (air) | |
| Pallet length (gross) | 80 cm |
| Pallet width (gross) | 120 cm |
| Pallet height (air) | |
| Certificates of conformity | CE, RoHS |
| Certification | |
| Main carton net weight | |
| Country of origin | |
| Width of the shipping box | |
| Shipping box length | |
| Shipping box height | |
| Shipping box weight | |
| Number of products per shipping carton | 3 piece (s) |
| Manufacturer |
