Z890 TAICHI 1851 ATX HDMI/USB-C DDR5 retail

Name: Z890 TAICHI 1851 ATX HDMI/USB-C DDR5 retail
SKU: 165910
Price: 438.13 EUR
Availability: InStock

€538.90

Asrock Z890 Taichi, Intel, LGA 1851 (Socket V1), Intel Core Ultra (Series 2), LGA 1851, DDR5-SDRAM, 256 GB

12 in stock

Categories: Mainboards & accessories, Motherboards - Intel

Description
Additional information

Description

Asrock Z890 Taichi. Processor manufacturer: Intel, Processor socket: LGA 1851 (Socket V1), Compatible processors: Intel Core Ultra (Series 2). Supported memory: DDR5-SDRAM, Maximum RAM: 256 GB, Memory type: DIMM. Supported storage drive interfaces: PCI Express 4.0, PCI Express 5.0, SATA III. Supported storage drives: HDD & SSD, RAID levels: 0, 1, 5, 10. Maximum resolution: 7680 x 4320 pixels. USB connectors: USB Type-A, USB Type-C

Additional information

Processor manufacturer	Intel
Processor socket	LGA 1851 (Socket V1)
Compatible processors	Intel Core Ultra (Series 2)
Supported processor slots	LGA 1851
Supported RAM	DDR5 SDRAM
Number of memory slots	4
RAM type	DIMM
Memory channels	Dual channel
ECC compatibility	Non-ECC
RAM memory maximum	256 GB
Characteristic	12V power connection, Antenna included, ATX power connector (24-pin), Bluetooth, Clear CMOS button, CPU fan connector, EPS power connector (8-pin), Ethernet/LAN, Front panel audio connector, HDCP, M.2 spacers included, Microphone input, RAID support, RGB LED header, S/PDIF output, Screws included, TPM connector, Unbuffered memory, WIRELESS INTERNET ACCESS
Supported storage drives	HDD & SSD
Supported storage drive interfaces	PCI Express 4.0, PCI Express 5.0, SATA III
Number of storage drives supported	10
RAID level	1, 10, 5
Parallel processing technology	Unsupported
Maximum resolution	7680 x 4320 pixels
Number of USB 2.0 interfaces	2
USB 3.2 Gen 1 (3.1 Gen 1) ports	2
USB 3.2 Gen 2x2 ports	1
SATA III connectors	4
Number of CPU fan connectors	2
Number of chassis fan plugs	4
Number of EPS power connections (4-pin)	2
Number of water pump connections	1
Number of RGB LED pin headers	4
Number of USB 2.0 ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Number of Type A ports	4
USB 3.2 Gen 2 (3.1 Gen 2) Number of Type A ports	4
Number of Ethernet LAN connections (RJ-45)	2
Number of HDMI connections	1
HDMI version	2.1
Headphone outputs	1
Amount of Thunderbolt ports	2
WiFi AP antenna socket	2
USB plug	USB Type-A, USB Type-C
Ethernet interface type	2.5 Gigabit Ethernet, 5 Gigabit Ethernet
LAN controller	Dragon RTL8125BG, Realtek RTL8126
Top WiFi standard	Wi-Fi 7 (802.11be)
WLAN standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Bluetooth version	5.4
Motherboard chipset	Intel Z890
Audio chip	Realtek ALC4082
Audio channels	5.1 channels
Product color	Black
Component for	Pc
Motherboard form factor	ATX
Motherboard chipset family	Intel
Supports Windows operating systems	Windows 11 x64
Certification	CE, CEC Tier II, ErP / EuP, FCC
PCI Express x16 slots (Gen 4.x)	1
PCI Express x16 slots (Gen 5.x)	1
Number of M.2 (M) slots	6
1. M.2 largest key size	2280
1. M.2 highest PCI Express generation	5.0
2. M.2 largest key size	2280
2. M.2 highest PCI Express generation	4.0
3. M.2 largest key size	2280
3. M.2 highest PCI Express generation	4.0
4. M.2 largest key size	2280
4. M.2 highest PCI Express generation	4.0
5. M.2 largest key size	2280
5. M.2 highest PCI Express generation	4.0
6. M.2 largest key size	2280
6. M.2 highest PCI Express generation	4.0
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
Broad	305 mm
Depth	244 mm
Supplied cables	SATA
Manufacturer	ASRock
