QNAP TS-h2490FU-7302P-128G 24-Bay all-flash NAS AMD EPYC 7302P NVMe Gen3x4 128GB RAM 2×2.5GbE LAN 4x25GbE SFP28

Description

QNAP TS-h2490FU. Type: NAS. Enclosure type: Rack (2U). Device class: Enterprise. Processor family: EPYC, Processor: 7302P, Processor frequency: 3 GHz. Memory capacity: 128 GB, Internal memory type: DDR4. Total installed storage capacity: 0 TB. Installed operating system: QuTS hero

ZFS-based, 24-bay U.2 NVMe all-flash storage with high performance and low latency for virtualized workloads, data centers, and 8K streams

The NVMe All-Flash TS-h2490FU is designed for extreme performance with high cost-effectiveness. Equipped with 24 U.2 NVMe Gen 3 x4 SSD bays, the TS-h2490FU delivers up to 661K / 245K IOPS for random reads and writes with ultra-low latency. The ZFS-based QuTS hero operating system supports inline data deduplication and compression to reduce I/O and SSD storage consumption, significantly extending the lifespan of SSDs while offering a higher price/performance ratio for all-flash storage arrays. Combined with virtually unlimited snapshots, real-time SnapSync, and petabyte-scale storage expansion capabilities, the TS-h2490FU is ideal for I/O-intensive and latency-sensitive applications, eliminating productivity bottlenecks in modern data centers, virtualization, and mission-critical backup/restore tasks.

Building a high-performance storage infrastructure for applications with high IOPS requirements
Virtualization
Eliminates storage bottlenecks for unstructured data and I/O-intensive workloads; ideal for server virtualization and virtual desktop infrastructure (VDI).

Data centers
Delivers ultra-low latency and high IOPS performance, enabling microsecond response times for data centers hosting critical business systems and data.

Media and Entertainment (M&E) Production
Enables smooth 4K/8K media streaming and post-production, supporting multimedia workflows with faster data transfer, access, and backup for greater efficiency.

2nd Generation AMD EPYC™ Processors and DDR4 ECC Memory
The TS-h2490FU is equipped with 2nd Generation AMD EPYC™ 7002 Series (Rome) processors. Based on the “Zen 2” architecture with state-of-the-art 7nm process technology, it provides up to 128 PCIe I/O lanes for a dedicated bandwidth of 32 Gb/s per SSD. Featuring DDR4 ECC memory that detects and corrects single-bit memory errors for greater reliability, the TS-h2490FU offers 8-channel modules and 16 Long-DIMM slots for handling memory-intensive workloads. With its immense computing power and multitasking capabilities, the TS-h2490FU is the ideal choice for uncompromising performance requirements for applications in HPC, virtualization, and hybrid/multi-cloud.

U.2 NVMe Gen 3 x4 all-flash storage array
The 2U rackmount TS-h2490FU features 24 drive bays for U.2 NVMe Gen 3 x4 SSDs, with each SSD featuring a dedicated bandwidth of 32 Gb/s to ensure optimal application response times. Combined with powerful ZFS data extraction and SSD optimization technologies, the TS-h2490FU provides a solid foundation for addressing the complexity and performance demands of today's constantly evolving data center workloads.

Enables high-speed data transfer with four 25GbE ports
The TS-h2490FU offers groundbreaking network connectivity with two pre-installed 25GbE SFP28 SmartNICs* (using the Broadcom NetXtreme®-E Series BCM57414, Mellanox® ConnectX®-4 Lx, or the same performance class SmartNIC). With failover and port bonding for up to 100 Gb/s bandwidth, the TS-h2490FU provides your organization with the bandwidth to handle even the most demanding applications, such as data centers, virtualization, high-volume file transfer, high-speed backup/restore, and multimedia transmission.

Use the M.2 PCIe NVMe SSD to U.2 adapter
Install one or more QDA adapters in the TS-h2490FU to cost-effectively maximize PCIe bandwidth utilization by using an M.2 PCIe NVMe SSD instead of a U.2 SSD to optimize data-intensive applications. It can also increase IOPS performance when configuring SSD caching. Users can monitor hard drive health and manage SSD usage via the QTS Storage & Snapshots Manager. The M.2 SSD integrated into the QDA adapter is hot-swappable.

Multiple PCIe Gen 4 slots for flexible expansion
The TS-h2490FU is equipped with five PCIe Gen 4 slots. With twice the I/O performance of PCIe Gen 3, the TS-h2490FU can utilize multiple PCIe cards to expand application potential.

Robust, parallelized hardware to boost all-flash NVMe performance
The TS-h2490FU features high-quality hardware with an expandable architecture that offers businesses high performance and low latency. Thanks to its removable motherboard tray design, IT staff can easily service the TS-h2490FU without having to remove it from the rack.

The ZFS-based QuTS hero operating system improves NAS performance and data integrity
QuTS hero combines the app-based QTS with the 128-bit ZFS file system, providing flexible storage management, comprehensive data protection, and optimized performance to address the complexity and performance demands of modern IT. From storage management and virtualization to collaborative media workflows, QuTS hero optimizes your mission-critical tasks.

Data integrity is key
QuTS hero's self-healing features ensure data integrity and reliability. Write Once, Read Many (WORM) is also supported.

Data reduction improves storage efficiency and performance
Inline data deduplication, compression, and compaction reduce file sizes to preserve storage capacity and optimize performance.

Multi-level cache technology
Main memory read cache (L1 ARC), second-level SSD read cache (L2 ARC), and the ZFS intent log (ZIL) for synchronous transactions with power loss protection are supported simultaneously to increase performance and security.

RAID Z provides reliable data protection
Multiple RAID levels enable flexible capacity utilization. RAID Triple Parity and Triple Mirror offer a higher level of data protection.

QSAL (QNAP SSD Antiwear Leveling) improves data security
SSD lifespan at RAID level is automatically and periodically detected to prevent simultaneous SSD failure and improve your data security and system reliability.

App Center ecosystem extends NAS functionality
Apps for backup/sync, virtual machines/containers, content management, productivity, and other functions can be used to expand the application potential of the TS-h2490FU.

Inline data deduplication, compression, and compaction improve SSD endurance
QuTS hero supports advanced block-based data reduction technologies (including inline data deduplication, compression, and compaction) to reduce file sizes, save storage capacity, and optimize performance. For example, if 20 virtual machines are replicated on a NAS using the same template, the storage requirements for all 20 virtual machines can be reduced by up to 95%. Whether for primary or backup storage, the TS-h2490FU optimizes storage utilization to provide a reliable storage cornerstone in the Big Data era. All-flash solutions thus achieve greater cost efficiency while improving random write performance and SSD endurance.

Optimization technologies for higher SSD performance and lifespan
Writing coalescence
Converts all random writes to sequential writes with reduced I/O, effectively increasing write performance in all-flash environments.

Pool overprovisioning
Dedicated storage space can be flexibly reserved in an SSD storage pool so that new data can be written to a complete block even when the pool is almost full, thus improving the performance of fragmented pools.

TRIM
Allows QuTS hero to inform SSDs, delete unnecessary data blocks and process the deletion tasks during system idle time, i.e. it does not have to wait for new data to be written to the block.

Real-time SnapSync ensures minimal RPO with real-time disaster recovery
Real-time SnapSync ensures that both the primary and secondary NAS maintain identical data. When data is written to the source, it is immediately written to the destination. If the primary NAS goes offline, IT staff can easily adjust the permission settings of the secondary NAS to ensure continuous operation. SnapSync provides the strongest support for uninterrupted business operations and helps users reduce the risk of data loss.

Snapshots multiply backup protection
With virtually unlimited, instant snapshots, you no longer have to worry. Copy-on-write technology creates snapshots almost instantly, without impacting ongoing data writing. Snapshot Replica replicates snapshot files to the backup NAS, simplifying data backup with version control.

HBS simplifies 3-2-1 backup plans
HBS centralizes backup, recovery, and synchronization for easy data transfer from the TS-h2490FU to another QNAP NAS, a remote server, or cloud storage. HBS supports QuDedup technology, which eliminates redundant data at the source and accelerates multi-version backup.

All-in-one hosting solution for virtual machines and containers
You can rely on Virtualization Station and Container Station for comprehensive virtualization support. Combined with the Network & Virtual Switch app, which enhances interoperability between virtual machines, containers, QNAP NAS, and other physical devices on the network, you can flexibly allocate physical and virtual network resources and simplify network deployment.

Virtualization Station
Run multiple virtual Windows®, Linux®, UNIX®, and Android™ machines and access them via web browser or Virtual Network Computing (VNC). Enterprises can run virtualized server applications on a single NAS without the need for additional physical servers.

Container Station
Get familiar with LXC and Docker® virtualization technologies, download applications from the integrated Docker Hub Registry®, import and export containers, and create a variety of microservices.

Single Root I/O Virtualization (SR-IOV)
By installing an SR-IOV compatible PCIe SmartNIC in the TS-h2490FU, you can allocate bandwidth resources from a physical network card directly to VMs. Because traffic bypasses the hypervisor vSwitch, it helps improve I/O throughput and network efficiency, ensuring reliable VM applications and lower CPU overhead.

License-free VMware® and Hyper-V backup device
With Hyper Data Protector, the TS-h2490FU becomes an agentless backup tool for unlimited VMware® vSphere and Microsoft® Hyper-V VM backup. Hyper Data Protector offers incremental backup, global deduplication, backup scheduling, and restore compression. Hyper Data Protector also backs up multiple VMs simultaneously, providing you with an affordable and reliable disaster recovery plan that ensures 24/7 operation of your services.

Moving business data to the cloud and low-latency access to cloud-based data
The TS-h2490FU seamlessly integrates the NAS with common cloud services. By deploying cloud storage gateways and enabling local caching, you can seamlessly utilize the cloud for storage, backup, and data recovery with low-latency access. This greatly assists in implementing affordable, flexible, and secure hybrid cloud applications.

HybridMount file-based cloud gateway
Flexibly expand storage capacity by connecting to cloud storage. QuTS hero apps let you manage and edit your cloud or multimedia files. HybridMount is ideal for online collaboration with file servers and file-level data analysis.

VJBOD Cloud block-based cloud gateway
VJBOD Cloud supports optimized NAS backup to object cloud storage. Block-based data transfer uploads random data and large files to the cloud in blocks, transferring only block-based volume or LUN changes (such as adding, modifying, or deleting). This is ideal for enterprise-level applications with high file transfer requirements, such as databases, VM volumes, and videos.

Powerful, reliable storage solution for virtualization
– Supports block-based iSCSI LUNs as a high-performance, reliable, and affordable storage solution for VMware®, Microsoft® Hyper-V®, and Windows Server® 2019 virtualization environments.

– Supports VMware VAAI and Microsoft ODX to improve performance by reducing server load for ESXi servers and Hyper-V, respectively; and supports QNAP vSphere Client Plug-in for more efficient operation and management in virtualization applications.

Building a cost-effective Fibre Channel SAN environment
SAN (Common Fibre Channel Storage Area Network) devices are often expensive. By installing a QNAP dual-port 16Gb/32Gb Fibre Channel expansion card in the TS-h2490FU, you have more budget-friendly options for adding a NAS to a SAN environment. The iSCSI and Fibre Channel app allows you to specify a Fibre Channel target. Furthermore, the LUN masking and port binding features provide an additional layer of data security.

More productivity applications

Boxsafe
Protect corporate cloud data by backing up/syncing files, emails, calendars, and contacts from Google™ Workspace and Microsoft® Office 365® to the TS-h2490FU.

Security Counselor
A security portal for reviewing vulnerabilities and receiving recommendations for improving NAS security. It also integrates antivirus and anti-malware scanning software.

Qsirch
QNAP's powerful, Google-like search tool helps you quickly find images, music, videos, documents, and emails using keywords, colors, and other search criteria. It also supports Qfiling to perform one-time or automatic archiving tasks based on your search criteria.
